DMC/开放结构压接工具系列
| DMC/开放结构压接工具系列 |
| M22520/5-01 (HX4) & M22520/10-01 (HX3) |
| DMC HX4和HX3系列压接工具具有可更换的压膜以便满足不用的应用要求。 |
| HX4重约21盎司. |
| HX3重约11盎司. |
| DMC169A (M83521/7-01) &DMC169 (M83507/9-01) 工具箱 |
| DMC169A和DMC169工具箱包含HX4压接工具,千分尺以及27套常用压膜。 |
| 常用压膜及工具清单 |
| DIE P/NDIE CLOSURE DIMENSIONS |
| DMC MILITARY NATIONAL STOCK A LENGTH B LENGTH |
| P/N ♦P/N NUMBER HEX. HEX. |
| HX4 M22520/5-01 5120-01-335-8575 Standard Crimp Tool frame |
| HXE4B N/A N/A Battery Powered Hydraulic Crimp Tool frame |
| HX23 N/A N/A Pneumatic Crimp Tool frame |
| HD37 N/A N/A Hydraulic Crimp Tool frame |
| HDE37B N/A N/A Battery Powered Hydraulic Crimp Tool frame |
| EHCY N/A N/A Electro-Hydraulic Crimp Tool frame |
| Y200P M22520/5-02 5120-01-335-8244 0.091 0.090 .068 .270 |
| Y196 M22520/5-03 5120-01-335-8245 0.128 0.3250 .105 .325 |
| Y152 M22520/5-04 5120-01-335-8246 0.138 0.090 .118 .27 |
| Y197 M22520/5-05 5120-01-335-8247 0.213 0.325 .178 .325 |
| Y203 M22520/5-06 5120-01-335-8248 0.128 0.094 |
| Y195 M22520/5-07 5120-01-335-8249 0.255 0.325 |
| Y215 M22520/5-08 5120-01-335-8250 0.128 0.375 |
| Y204P M22520/5-09 5120-01-335-8251 0.178 .400 .068 .093 |
| Y189 M22520/5-10 5120-01-335-8252 0.160 .400 |
| Y205P M22520/5-11 5120-01-335-8253 0.213 .400 .068 .093 |
| Y206P M22520/5-13 5120-01-335-8254 0.255 .400 .068 .093 |
| Y207P M22520/5-15 5120-01-335-8255 0.263 .400 .068 .093 |
| Y193 M22520/5-17 5120-01-335-8256 0.118 .375 |
| Y142 M22520/5-19 5120-01-335-8257 0.255 .400 .213 .400 |
| Y149 M22520/5-21 5120-01-335-8258 0.475 .400 |
| Y145 M22520/5-23 5120-01-335-8259 0.384 .400 |
| Y110P M22520/5-25 5120-01-335-8260 0.429 .400 .100 .120 |
| Y151 M22520/5-27 5120-01-335-8261 0.532 .400 |
| Y109P M22520/5-29 5120-01-335-8262 0.324 .400 .100 .120 |
| Y150 M22520/5-31 5120-01-335-8263 0.501 .400 |
| Y136 M22520/5-33 5120-01-335-8264 0.343 .400 .105 .400 |
| Y137 M22520/5-35 5120-01-335-8265 0.324 .400 .128 .400 |
| Y138 M22520/5-37 5120-01-335-8266 0.314 .400 .151 .400 |
| Y139 M22520/5-39 5120-01-335-8267 0.309 .400 .160 .400 |
| Y140 M22520/5-41 5120-01-335-8268 0.290 .400 .178 .400 |
| Y141 M22520/5-43 5120-01-335-8269 0.268 .400 .197 .400 |
| Y143 M22520/5-45 5120-01-335-8270 0.231 .400 .218 .400 |
| Y144 M22520/5-47 5120-01-335-8271 0.359 .400 |
| Y146 M22520/5-49 5120-01-335-8292 0.401 .400 |
| Y147 M22520/5-51 5120-01-335-8293 0.431 .400 |
| Y148 M22520/5-53 5120-01-335-8294 0.454 .400 |
| Y102 M22520/5-55 5120-01-335-8295 0.324 .400 |
| Y209P M22520/5-57 5120-01-335-8296 0.213 .400 .100 .120 |
| Y208P M22520/5-59 5120-01-335-8297 0.255 .400 .100 .100 |
| Y178 M22520/5-61 5120-01-335-8298 0.429 .400 |
| Y314P M22520/5-63 5120-01-335-8299 0.263 .400 .091 .091 |
| Y501 M22520/5-100 5120-01-335-8300 Pre-Insulated Terminal Crimp 26-10 AWG |
| Y527 M22520/5-101 5120-01-335-8301 Pre-Insulated Splice Crimp 26-20 AWG |
| Y539 M22520/5-102 5120-01-335-8302 Splice Crimp 12-16 AWG |
| Y540 M22520/5-103 5120-01-335-8303 Splice Crimp 16-26 AWG |
| Y631 M22520/5-105 5120-01-361-9554 .218 .307 |
| ♦ Die part numbers ending in "P" indicate the the die set has an alignment pin. |
| Non-military dies are available for a range of applications. Contact DMC for Details. |
| Common Hex Dies for HX3 & PHX3 |
| DIE P/NDIE CLOSURE DIMENSIONS |
| DMC MILITARY NATIONAL STOCK A LENGTH B LENGTH |
| P/N ♦P/N NUMBER HEX. HEX. |
| HX3 M22520/10-1 5120-01-335-8582 Miniature Crimp Tool frame |
| PHX3 -- -- Pneumatic Crimp Tool frame |
| X115S M22520/10-2 5120-01-335-83040 .091 .090 .068 .270 |
| X103 M22520/10-3 5120-01-335-83050 .255 .325 |
| X123 M22520/10-4 5120-01-335-82770 .138 .090 .118 .270 |
| X101 M22520/10-5 5120-01-335-82780 .128 .325 .105 .325 |
| X125 M22520/10-6 5120-01-335-82790 .160 .400 |
| X102 M22520/10-7 5120-01-335-82800 .213 .325 .178 .325 |
| X140 M22520/10-8 5120-01-335-82810 .128 .093 |
| X129 M22520/10-9 5120-01-335-82820 .118 .327 |
| X136 M22520/10-10 5120-01-335-82830 .128 .375 |
| X225 M22520/10-11 5120-01-335-82840 .105 .400 |
| X118 M22520/10-13 5120-01-335-82850 .128 .400 |
| X226 M22520/10-15 5120-01-335-82860 .151 .400 |
| X149 M22520/10-17 5120-01-335-82870 .178 .400 |
| X147 M22520/10-19 5120-01-335-82880 .197 .400 |
| X144 M22520/10-21 5120-01-335-82890 .213 .400 |
| X155 M22520/10-23 5120-01-335-82900 .218 .400 |
| X156 M22520/10-25 .231 .400 |
| X187 M22520/10-27 5120-01-335-82910.2550.4 |
| X515 M22520/10-100 5120-01-335-8272 Terminal/Splice Crimp 12-10 AWG |
| X511 M22520/10-101 5120-01-335-8273 Terminal/Splice Crimp 26-14 AWG |
| X525 M22520/10-102 5120-01-335-8274 Terminal/Splice Crimp 26-24 AWG |
| X527 M22520/10-103 5120-01-335-8275 Splice Crimp 16-12 AWG |
| X528 M22520/10-104 5120-01-335-8276 Splice Crimp 26-16 AWG |
| 更多产品型号选择请咨询 |
